RMS N4000W-PS SDL Required (Requires Forward Seal Disc and Item 98FSDSS)

The AeroTech Reloadable Motor System RMS is an aluminum cased reusable motor in kit form that is assembled by the user. You will need AeroTech RMS-98/20480 motor hardware to build and complete the motor for many reliable flights. Motor hardware is available separately in a complete set, and also as individual parts. This motor requires installing a forward seal disc Stainless Steel (98FSDSS) during assembly. Important: High Power RMS reload kits are not compatible with Mid Power RMS products.

The N4400W-PS is a Plugged/Smoke motor reload. Plugged reload kits do not utilize a motor-actuated delay or ejection charge. Plugged motors must be used in conjunction with a timer, altimeter or radio-activated recovery system.

This RMS motor reload utilizes RCS' exclusive White Lightning™ aerospace grade composite propellant formulation.

The AeroTech motor reload kit comes with 1 rocket motor reload. Reload kits include all internal motor components and FirstFire™ Initiators.  Also, this motor requires special handling by Euro Space Tech!

Certified by the Tripoli Rocketry Association (TRA), the National Association of Rocketry (NAR) and the Canadian Association of Rocketry (CAR).

Specifications:

Motor Diameter: 3.875 inches (98mm)

Casing Length: 41.18 inches (1046mm)

Hardware Required: RMS-98/20480

Total Impulse: 18540 N-sec

Peak Thrust: 5320 N-sec

Thrust Duration: 4.6 seconds

Delay Time: Plugged with Smoke

Propellant Weight: 9800 grams

Motor Weight: 16252 grams

Maximum Liftoff Weight: Due to the variables involved, AeroTech/Quest currently does not list or post recommended maximum lift-off weights for their mid-power and high-power rocket motors. Instead, we recommend utilizing either the RockSim software available at www.apogeerockets.com or OpenRocket Simulator available at www.openrocket.info.
